Home > Products > Bulldozer

2.46ton Bulldozer SD23



Quick Details

Feature: Bulldozer

Condition: New

Application: Construction

Brand Name: SHANTUI

Model Number: SD23

Certification: ISO,CE

Rated Loading Capacity: 2.46t

Bucket Capacity: 7.8m3

Dimension:  5528*3725*3741mm

Max. Lifting Load: 2.46t

Engine: NTA855-C280S10

Place of Origin: Jiangsu, China (Mainland)

Warranty: 1 year

Color: Yellow

After-sales Service Provided: Engineers available to service machinery overseas


Packaging & Delivery

Packaging Details:

Nude package Shipped by Ro-Ro or Bulk shipment

Delivery Detail:

7~15 days


Main Features

1. More excellent performance
2. More reliable quality
3. Easier to operate
4. Easier to maintain
5. More energy-efficient and environmental friendly

Technical Parameters

Dimension

Unit

SD23

Overall length

mm

5528

Overall width

mm

3725

Overall height

mm

3741

Ground contact length of track

mm

3150

Track shoe width

mm

560

Weight





Total weight

kg

24600

Power





Engine model



NTA855-C280S10

Engine rated power

kW

180

Engine rated speed

r/min

2000

Travel





Travel speed 1st (forward/backward)

km/h

0~3.8/0~4.9

Travel speed 2st (forward/backward)

km/h

0~6.8/0~8.5

Main performance





Operation weight

t

24.6

Blade capacity

m3

7.8

Gradeability

0

30

Ground pressure

kpa

0.078

Shovel blade width

m

3.725/1.395

Shovel blade height

m

1.59

Max. hoisting height

m

1.56

Max. digging depth

m

0.56

Max. gradient

m



Track gauge

m

2

Caterpillar track pitch

m

0.2286

Min. swing radius

m



Min. ground clearance

m
