125ton Crawler Crane SCC1250

Quick Details

Feature: Crawler Crane	Condition: New	Application: Construction
Brand Name: SANY	Model Number: SCC1250	Certification: ISO,CE
Rated Loading Capacity: 125t	Rated Lifting Moment: 6544.44kN.M	Dimension:  mm
Max. Lifting Load: 125t	Max. Lifting Height: 75m	Place of Origin: Jiangsu, China (Mainland)
Warranty: 1 year	Color: Yellow	After-sales Service Provided: Engineers available to service machinery overseas

---

Packaging & Delivery

Packaging Details:	Nude package Shipped by Ro-Ro or Bulk shipment
Delivery Detail:	10 days

---

Main Features

1. More excellent performance 2. More reliable quality 3. Easier to operate 4. Easier to maintain 5. More energy-efficient and environmental friendly

Technical Parameters

Dimension	Unit	SCC1250
Overall length	mm
Overall width	mm
Overall height	mm
Weight
Total mass (with basic boom)	t	124.5
Max. single shipping weight	t	42
Power
Engine model
Engine rated power	kW/(r/min)	183/2000
Engine rated torque	N.m/(r/min)
Travel
Max. travel speed	km/h	0.68/1.0
Max. grade ability	%
Mean ground pressure	MPa
Main performance
Max. rated total lifting capacity	t	125
Max. lifting torque	kN.m	6544.44
Base boom	m	18
Fully extended boom	m	75
Fully extended boom+ jib	m	100
Boom elevating angle	°
Working speed
Max. swing speed	r/min	0~2.2
Max. single rope hoist speed	m/min	0~110
Max. single rope boom luffer speed	m/min	0～90
