55ton Crawler Crane SCC550C

Quick Details

Feature: Crawler Crane	Condition: New	Application: Construction
Brand Name: SANY	Model Number: SCC550C	Certification: ISO,CE
Rated Loading Capacity: 55t	Rated Lifting Moment: 1994.3kN.M	Dimension: 7110*3300*3260mm
Max. Lifting Load: 55t	Max. Lifting Height: 52m	Place of Origin: Jiangsu, China (Mainland)
Warranty: 1 year	Color: Yellow	After-sales Service Provided: Engineers available to service machinery overseas

---

Packaging & Delivery

Packaging Details:	Nude package Shipped by Ro-Ro or Bulk shipment
Delivery Detail:	10 days

---

Main Features

1. More excellent performance 2. More reliable quality 3. Easier to operate 4. Easier to maintain 5. More energy-efficient and environmental friendly

Technical Parameters

Dimension	Unit	SCC550C
Overall length	mm	7110
Overall width	mm	3300
Overall height	mm	3260
Weight
Total mass (with basic boom)	t	49
Maximum lifting weight of fixed jib	t	17.5
Power
Engine model
Engine rated power	kW/(r/min)	114/2200
Engine rated torque	N.m/(r/min)
Travel
Max. travel speed	km/h	1.39
Max. grade ability	%	40
Mean ground pressure	MPa	0.061
Main performance
Max. rated total lifting capacity	t	55
Max. lifting torque	kN.m	1994.3
Base boom	m	13
Fully extended boom	m	52
Fully extended boom+ jib	m	58.25
Boom elevating angle	°	30-80
Working speed
Max. swing speed	r/min	0~3.2/1.6
Max. single rope hoist speed	m/min	102/63
Max. single rope boom luffer speed	m/min	0~73
