39.5ton Reach stacker LG260EC6



Quick Details

Feature: Reach stacker

Condition: New

Application: Construction

Brand Name: LONKING

Model Number: LG260EC6

Certification: ISO,CE

Total Weight: 39.5t

Rated Payload: 9000kg

Max. Layers of Stacking: 5*9'6'' / 6*8'6''

Max. Travel Speed: 28km/h

Max. Lift Speed: 630/730mm/s

Max. Lowering Speed: 600mm/s

Warranty: 1 year

Max. Gradeability: 28%

After-sales Service Provided: Engineers available to service machinery overseas


Packaging & Delivery

Packaging Details:

Nude package Shipped by Ro-Ro or Bulk shipment

Delivery Detail:

10 days


Main Features

1. More excellent performance
2. More reliable quality
3. Easier to operate
4. Easier to maintain
5. More energy-efficient and environmental friendly

Technical Parameters

Dimension

Unit

LG260EC6

A (Overall length)

mm

6840

B (Wheel base)

mm

4500

C (Load center distance)

mm

1220

D (Track width, rear)

mm

2330

E (Track width, front)

mm

3270

F (Overall width of the machine)

mm

4135

G (Overall width of the lifting device)

mm

6100

H (Overall height of machine)

mm

4400

H1 (The min. height from the ground to the lock)

mm

2380

H2 (Mast height at upright)

mm

9800

H3 (Max. lifting height)

mm

16400

H4 (Overall height when the mast is fully extended)

mm

16830

Weight





Total weight in travel

kg

39500

Power





Engine model



VOLVO TAD 720VE

Engine rated power

KW(hp)/rpm

174(237)/2300

Peak torque

Nm/rpm

854/1400

Travel





Max. travel speed

km/h

28

Max. traction force

KN(2km/h)

128

Main performance





Number of wheels (front/rear)



4/2

Mast tilting angle (forward/rackward)

0

2/4

Max. lift speed

mm/s

630/730

Max. lowering speed

mm/s

600

Max. gradeability

%

28

Min. turning radius

mm

6050

Front axle load (with/without Load)

kg

40700/27700
