40ton Truck Crane QY40K

Quick Details

Feature: Truck Crane	Condition: New	Application: Construction
Brand Name: XCMG	Model Number: QY40K	Certification: ISO,CE
Rated Loading Capacity: 40t	Rated Lifting Moment: 1400kN.M	Dimension: 13050*2800*3430mm
Max. Lifting Load: 60t	Max. Lifting Height: 55.1m	Place of Origin: Jiangsu, China (Mainland)
Warranty: 1 year	Span: 6.6m	After-sales Service Provided: Engineers available to service machinery overseas

---

Packaging & Delivery

Packaging Details:	Nude package Shipped by Ro-Ro or Bulk shipment
Delivery Detail:	10 days

---

Main Features

1. More excellent performance 2. More reliable quality 3. Easier to operate 4. Easier to maintain 5. More energy-efficient and environmental friendly

Technical Parameters

Dimension	Unit	QY40K
Overall length	mm	13050
Overall width	mm	≤2800
Overall height	mm	3430
Weight
Total weight in travel	kg	40400
Front axle load	kg	14500
Rear axle load	kg	25900
Power
Engine model		WD615.334
Engine rated power	kW/(r/min)	247/2200
Engine rated torque	N.m/(r/min)	1350/1400
Travel
Max. travel speed	km/h	75
Min. turning diameter	m	≤24
Min. ground clearance	mm	285
Approach angle	°	16
Departure angle	°	11
Max. grade ability	%	46
Fuel consumption for 100km	L	46
Main performance
Max. rated total lifting capacity	t	40
Min. rated working radius	m	3000
Turning radius at turntable tail	m	3.482
Max. lifting torque	kN.m	1400
Base boom	m	10.7
Fully extended boom	m	40.1
Fully extended boom+ jib	m	55.1
Longitudinal outrigger span	m	5.65
Lateral outrigger span	m	6.6
Working speed
Boom luffing time	s	≤88
Boomfull extension time	s	≤180
Max. swing speed	r/min	≥2.0
Max. speed of main winch (single rope) (no load)	m/min	≥110
Max. speed of aux. winch (single rope) (no load)	m/min	≥110
