20ton Truck Crane QY20G.5

Quick Details

Feature: Truck Crane	Condition: New	Application: Construction
Brand Name: XCMG	Model Number: QY20G.5	Certification: ISO,CE
Rated Loading Capacity: 20t	Rated Lifting Moment: 860kN.M	Dimension: 12400*2500*3320 kW/rpm
Max. Lifting Load: 20t	Max. Lifting Height: 32.76m	Place of Origin: Jiangsu, China (Mainland)
Warranty: 1 year	Span: 4.97/5.4m	After-sales Service Provided: Engineers available to service machinery overseas

---

Packaging & Delivery

Packaging Details:	Nude package Shipped by Ro-Ro or Bulk shipment
Delivery Detail:	10 days

---

Main Features

1. Max lifting weight:20ton 2. Engine shangcai 192KW 3. Fully extended boom+jib42.12m 4. Engine:SC8DK260Q3 5. Base boom:833KN.m

Technical Parameters

Dimension	Unit	QY20G.5
Overall length	mm	12400
Overall width	mm	2500
Overall height	mm	3320
Weight
Total weight in travel	kg	26020
Front axle load	kg	6900
Rear axle load	kg	19120
Power
Engine model		SC8DK260Q3, WD615.327
Engine rated power	kW/(r/min)	192/2200, 198/2200
Engine rated torque	N.m/(r/min)	1100/1400, 1150/1400
Travel
Max. travel speed	km/h	75
Min. turning diameter	m	20
Min. ground clearance	mm	275
Approach angle	°	16
Departure angle	°	13
Max. grade ability	%	24
Fuel consumption for 100km	L	≈35
Main performance
Max. rated total lifting capacity	t	20
Min. rated working radius	m	3
Turning radius at turntable tail	m	3.385
Max. lifting torque	kN.m	860
Base boom	m	10.06
Fully extended boom	m	32.76
Fully extended boom+ jib	m	42.12
Longitudinal outrigger span	m	4.97
Lateral outrigger span	m	5.4
Working speed
Boom luffing time	s	75
Boomfull extension time	s	95
Max. swing speed	r/min	3
Max. speed of main winch (single rope) (no load)	m/min	100
Max. speed of aux. winch (single rope) (no load)	m/min	100
