5.78ton Excavator SY55C-9

Quick Details

Feature: Excavator	Condition: New	Application: Construction
Brand Name: SANY	Model Number: SY55C-9	Certification: ISO,CE
Rated Loading Capacity: 5.78t	Bucket Capacity: 0.1-0.28m3	Dimension:  5925*2005*2595mm
Max. Lifting Load: 5.78t	Engine: 4JG1-NABGB-04-C2	Place of Origin: Jiangsu, China (Mainland)
Warranty: 1 year	Color: Yellow	After-sales Service Provided: Engineers available to service machinery overseas

---

Packaging & Delivery

Packaging Details:	Nude package Shipped by Ro-Ro or Bulk shipment
Delivery Detail:	7~15 days

---

Main Features

1. More excellent performance 2. More reliable quality 3. Easier to operate 4. Easier to maintain 5. More energy-efficient and environmental friendly

Technical Parameters

Dimension	Unit	SY55C-9
Overall length	mm	5925
Overall width	mm	2005
Overall height	mm	2595
Track shoe length	mm	2545
Track shoe width	mm
Weight
Total weight	kg	5780
Power
Engine model		4JG1-NABGB-04-C2
Engine rated power	kW	40.9
Engine rated speed	r/min	2100
Travel
Travel speed	km/h	3.73/2.4
Main performance
Rated load	t	5.78
Bucket capacity	m3	0.1-0.28
Gradeability	0	70
Ground pressure	kpa	32.75
Bucket digging force	KN	45
Arm digging force	KN	33
Max. tractive force	KN
Max. dumping clearance	m	3.93
Max. digging depth	m	3.815
Max. digging radius	m	6.09
Min. swing radius	m	2.555
Steering speed	r/min	9.6
Track gauge	m	1.6
Caterpillar wheelbase	m	2.045
Min. ground clearance	m	0.33
